USER-FRIENDLY SOFTWARE INTERFACE

• Intuitive software interface developed for the needs of professional locksmiths, with shortcuts to the most used cutting cards and job queues

• Works in stand-alone

• Compatible with SKP Pro to work with existing data archives and Codemaker cards

PROFESSIONAL DISPLAY

• Integrated, industrial 10-inch, touch-screen display

• Tilts to give the perfect viewing angle

• Immediate response to the touch (0,01 seconds)

• Colour display with a resolution of 1280×800 pixels

FULL CONNECTIVITY

• Connection both via Wi-Fi and via Ethernet to the local LAN Network

• 4 USB ports (2 ports 3.0 + 2 ports 2.0)

• HDMI port to connect an external screen

• Possibility to connect a wireless keyboard and mouse

CLEANER, SAFER, AND MORE COMFORTABLE WORKING AREA

•The machine is completely enclosed: swarf is collected in the tray below the cutting area to leave the working area clean

• The safety shield closes and opens automatically when starting or ending a cycle

• The shield features two microswitches and stops automatically if obstructed to give additional protection •55% bigger working area compared to previous models for easier operation

TOP PERFORMANCE AND AUTOMATED, DOUBLE-SIDED MARKING

• Prismatic cutters and engraving cutters are made of hard metal for precise results and resistance to wear

• Process time is dramatically reduced: no need to install a separate tool or to move the key manually for engraving • Both key sides can be independently marked

QUIET • New structure optimized to absorb vibrations and noise

• Less vibrations thanks to the new 80 teeth cutter in hard metal (widia)

• A completely enclosed working area reduces noise during marking and cutting

CAMERA READER FOR FAST OPTICAL DECODING

• Unique, patent-pending solution for immediate decoding

• No positioning needed: just drop the key in the pull-out compartment

• The software shows the difference between the depths read and the depths defined by the manufacturer

• Double-sided keys with asymmetrical cuts and single-sided keys with protrusions such as ball bearings or other patented design elements cannot be decoded

FOUR-SIDED, VERSATILE CLAMP

• Four-sided clamp for optimized blocking of a wide variety of keys, both with head and tip stop

• Ergonomic and dynamometric knob for an easy key installation

• Nickel plating for better resistance to rust and wear • Wide gauge with mobile stop fits keys with tip stops perfectly • The software shows which clamp side and which stop you should use

UNOCODE F600 SOFTWARE For the Unocode F Series key machines we have developed an entirely new software, engineered specifically to make your job easier and quicker. The new interface can also be customized according to your needs so that you can keep within easy reach of the functions you use most frequently. •Cutting cards comparison available on board •Cutting cards shortlist*: when decoding a key, you don’t have to select a cutting card first. The camera reader decodes the key cuts and provides you with a shortlist of cards from which you can choose the one you need •Code tables available on board* •Customize your favorites: you can rename the cutting cards you use most frequently and reorder them according to your needs •Onboard video tutorials and product manual •Remote service to support you when needed * Coming soon with a software update
